Durable Construction: Made from rust-free brass for longevity

Cost-Effective: Budget-friendly option for retrofitting existing openings for hands-free operation

Aesthetically Pleasing: Designs that complement building style

Hands-Free Operation: Enables operation with arm, elbow, or wrist

Patented Rounded Design: Ensures safe and comfortable use and allows for flexible installation toward hinge or latch side

Pull Plate Option: 8322HD available with 4 x 16" or 6 x 16" pull plate. Easily retrofits to existing openings

Material: Brass

Certifications:

UL10C listed for 3-hours (F, I, L mounted pull only)

ADA Compliant design

Mounting Hardware:

Heavy-duty mounting hardware exceeds industry standards

Optional mounting hardware available (see general information section for details)

Specify PR when ordering a set of pulls for back-to-back mounting

For one back-to-back machined pull, specify NSGL or PSGL (glass doors)

8122HD/8322HD Series:

8" Pull: 17 1⁄2" (H) x 3 5⁄8" (W) x 4" (D)

10" Pull: 19 1⁄2" (H) x 3 5⁄8" (W) x 4" (D)

8" Center to Center:

Projection: 4"

Clearance: 1 1⁄2"

Center to center: 8"

Overall length: 17 1⁄2"

10" Center to Center:

Projection: 4"

Clearance: 1 1⁄2"

Center to center: 10"

Overall length: 19 1⁄2"

Matte Black (US19): BHMA 622

Satin Chrome (US26D): BHMA 626

Dark Bronze Powder Coat (SP313/US10BE): BHMA 695
