ARCHITECTURAL HINGES

Finish:

Features & Benefits

Architectural Hinges
Body Construction

Cast iron cylinder
Full-complement bearing
1-1/2” diameter piston

Quality and Durability

All-weather fluid
Forged steel arm
15-year warranty

Installation

Handed design for right- and left-swinging doors
Wood and machine screw pack
Adjustable spring sizes 1-6

Form Factors

Standard or optional custom powder coat finish
Optional plated finish on metal cover, arm and fasteners
Optional SRI primer for installations in corrosive conditions is available with powder coat only

Specifications

Sized cylinders for interior doors to 5’0” and exterior doors to 4’0”
Meets ADA requirements
UL and cUL listed for self-closing doors without hold-open
Tested and certified under ANSI/BHMA A156.4 Grade 1
For hollow metal or wood doors and frames

Smart vs. Proximity

Smart vs. Prox - Making the switch

Proximity

Data is stored but not encrypted
Rigid storage that can’t be changed
Can only store one number
Slower communication speed
Easily duplicated

Smart

Data is stored and encrypted
Has dynamic storage that can be changed
Can store a variety of data
Faster communication speed
Difficult to duplicate

With Schlage® multi-technology readers and multi-technology credentials, you can transition systems from an existing population of magnetic stripe or proximity cards to more secure smart card technology at your own pace.

Consult your Allegion representative

Downloads & Resources

Templates / Installation Instructions

2010 Series

All Mounts / Installation Instructions 18755

5010 Series

All Mounts / Installation Instructions 13178

LCN Installation Instructions/Templates Index

ARCHITECTURAL HINGES

NDE wireless locks are integrated into popular PACS provider systems and now offer a mobile enabled option to read Bluetooth and NFC mobile credentials.
